R11 DB Superleggero Disc Brake Bike Frameset
Regular price
€1.136,00
Sale price
€1.470,00
Unit price per
La R11 è leggerissima, con soli 850 grammi per il telaio e 390 grammi per la forcella (taglia 54 cm). Questo telaio rigido e reattivo fa sì che a ogni pedalata l'energia venga trasferita direttamente al suolo, esattamente dove si vuole. Con una maneggevolezza veloce per le discese, è il partner perfetto. L'unica cosa che resta da fare è vedere quale sarà la prossima collina da scalare.
| Size Dimension | L Reach |
M Stack |
A Top Tube Length |
B Head Tube Length |
C Seat Tube Angle |
D Head Tube Angle |
E BB Drop |
F Chain Stay |
G Wheel Base |
H BB to Front Wheel |
I Fork Length |
J Fork Rake |
K Seat Tube Length |
| 49CM | 373 | 514 | 520 | 110 | 74° | 72.5° | 69 | 410 | 965 | 565 | 370 | 45 | 455 |
| 52CM | 384 | 523.5 | 535 | 120 | 74° | 72.5° | 69 | 410 | 975 | 579.5 | 370 | 45 | 475 |
| 54cm | 385 | 541 | 545 | 136 | 73.5° | 73° | 69 | 410 | 975 | 580.2 | 370 | 45 | 495 |
| 56CM | 394.5 | 557 | 560 | 155 | 73.5° | 73° | 69 | 410 | 990 | 594.9 | 370 | 45 | 515 |
| 59CM | 398 | 582 | 575 | 175 | 73° | 73.5° | 69 | 410 | 995 | 600 | 370 | 45 | 535 |
Sizing & Fit:
The charts below show our recommended sizes based on height, but there are some other factors, like arm and leg length, that determine a great fit.
That’s why you’ll see some overlap in our recommendations.
| Size | XS 49CM |
S 52CM |
M 54CM |
L 56CM |
XL 59CM |
| Rider Height | 165-173CM | 170-178CM | 175-183CM | 180-188CM | 185-193CM |
LIGHT AS A FEATHER
The R11 is the most lightweight bike of our lines with just *850grms for the frame and 390grm for the fork (*size 54cm). This stiff and responsive frame is an energy carrier, transferring your energy directly onto the ground precisely where you want it every time you stroke the pedal. With fast handling for the descent, it makes the perfect climbing partner.
LIGHT AS A FEATHER
The R11 is the most lightweight bike of our lines with just *890 grams for the frame (*size 49cm). This stiff and responsive frame is an energy carrier, transferring your energy directly onto the ground precisely where you want it every time you stroke the pedal. With fast handling for the descent, it makes the perfect climbing partner.
EPS+LATEX PRODUCTION TECH FOR HANDLEBAR AND FRAME
Moulded by one piece monobloc with EPS+LATEX tech makes the handlebar much stiffer and smoother internally, yet easier for cable routing.
CRAFTED WITH PROMOLDCORE
A pinnacle of manufacturing prowess, ProMoldCore technology transcends traditional methods, crafting high-end carbon fiber cycling frames with intact precision. Embrace ideal stability as latex molds the frame's interior, setting the seal on a wrinkle-free with smooth finish inside out.
ROUTE IT LIKE A PRO
Our internal cable routing system, known as the ProRoute system, is designed to accommodate both mechanical and electronic groupsets. This innovative feature keeps your cables tucked away and protected, resulting in a clean, streamlined appearance and reduced maintenance.
MORE COMFORT WITH EXTRA COMPLIANCE
Combining the D-shaped seatpost and our new slider saddle-clamp design, it will be much easier for you to adjust your position and be comfortable. This design will also keep you safe on gravel roads as it prevents the saddle from accidentally tilting, while giving you some more extra compliance.
THE BIGGER, THE BETTER
Want to spice up your workout with those uphills or go for light gravel? Simply replace the current tire with 32c and chunkier all-terrain rubber. Yoeleo R11 now supports wide road tires including 32mm of clearance for increased traction and comfort on the road.
ST1 STEM+ H11 DROP BAR OPTION
Our standard handlebar for R11 is H9, it is integrated handlebar, we also offer the stem and bar option: ST1 Stem + H11 handlebar. If you want the ST1 stem+ H11 handlebar to replace the H9, please send us email after yo place the order.
Check More
APPROVED BY THE UCI
The R11 has received approval from the Union Cycliste Internationale (UCI). Our dedication to the highest quality and safety standards in the cycling industry ensures that we fully support your professional cycling journey.
RIDE WITH PRIDE
Our product comes with a 6-year warranty, providing you with confidence and assurance in its enduring quality and reliability.
YOUR SAFETY MATTERS
While we sincerely hope you won't require it, we provide a 30% crash replacement discount on all handlebars and spares in the unfortunate event of a crash. Reach out to us, and we'll strive to assist you promptly, ensuring you can get back on the road and ride again as soon as possible.
